RUIJIE REYEE RG-RAP2260(H) AX6000 Wi-Fi 6 2 X 2,5G PORT 4x4 MU-MIMO 2.4 GHZ & 5 GHZ POE ADAPTORSUZ INDOOR ACCESS POINT
7.939,49 ₺
7.383,73 ₺
KdvDahil
* 896,79 ₺ den
başlayan taksitlerle!
başlayan taksitlerle!
7.088,38 ₺
(%4,00 havale indirimi)
Toplu Satın Al
Değerli Müşterimiz ;
Koli Bazlı ve Toptan Olarak Almak İstediğiniz Ürünlere Bu Ekrandan Özel Teklif Alabilirsiniz.
Vereceğiniz Bilgiler Doğrultusunda Satın Alma Uzmanlarımız Size Özel Fiyat Teklifi Verecektir.
RUIJIE REYEE RG-RAP2260(G) AX1800 Wi-Fi 6 2PORT 2.4G 2x2MIMO 5G 2x2MIMO 23dBm 2.4 GHZ & 5 GHZ POE ADAPTORSUZ INDOOR ACCESS POINT
Reyee 2021 New Indoor Access Point
Innovation, Wi-Fi 6
A Big Leap Forward in Wireless Experience
802.11ax(Wi-Fi 6) adopts the OFDMA, 1024QAM, MU-MIMO and other multiple key technology.
Supports faster speed, more concurrent users with lower multi-users network delay.
For RG-RAP2260(G), both 2.4GHz and 5GHz comply with Wi-Fi 6 standard.
BSS Coloring
Intelligent Anti-jamming*
TWT
Terminal Energy Saving*
Performance Upgraded
Recommended Concurrent Users Up to 100
Dual-Band, dual Stream, AX1775 throughput, all gigabit ports.
Upgraded performance for higher bandwidth and better Wi-Fi experience requirements.
ModelWireless SpeedPortConcurrent Users
(Recommended/Max)
RG-RAP2260(G)1775Mbps2 GE LAN100/512
One Little Detail,
More Scientific and Technological Sense
More Details, More Possibilities
Dual LAN Port
RG-RAP2260(G) supports 2 gigabit ports for uplink and LAN extension.
The shell is made of novel flame retardant material, and its strength is 5 times higher than common ABS
Tensile Strength
Increased by 30%
Non-directional Mount KitFlexible installation for all scenarios.
Layer 3 Roaming
Wherever You Are, You Get Full Signal
Roaming smoothly between APs which in different VLANs
- Financial Department
- Sales Department
- CEO Office
- Meeting Room
|
Model |
RG-RAP2260(G) |
|
|
Radio |
Dual-stream dual-band |
|
|
Protocol |
Concurrent 802.11ax, 802.11ac wave2/wave1, 802.11a/b/g/n |
|
|
Operating Bands |
802.11b/g/n/ax ：2.4G ~ 2.4835GHz 802.11a/n/ac/ax ： 5G：5.150～5.350GHz，5.725～5.850GHz (country specific) |
|
|
Antenna |
Internal antennas(2.4G: 3dBi，5G: 3dBi) |
|
|
Spatial Streams |
2.4G 2x2MIMO 5G 2x2MIMO |
|
|
Max Throughput |
Up to 574Mbps at 2.4G Up to 1201Mbps at 5G 1.775Gbp per AP |
|
|
Modulation |
OFDM： BPSK@6/9Mbps，QPSK@12/18Mbps，16QAM@24Mbps，64QAM@48/54Mbps
DSSS： DBPSK@1Mbps，DQPSK@2Mbps， and CCK@5.5/11Mbps
MIMO-OFDM： BPSK，QPSK，16QAM ，64QAM，256QAM and1024QAM
OFDMA |
|
|
Receive Sensitivity |
11b： -96dBm(1Mbps)， -93dBm(5Mbps)， -89dBm(11Mbps)
11a/g： -91dBm(6Mbps)， -85dBm(24Mbps)， -80dBm(36Mbps)， -74dBm(54Mbps)
11n： -90dBm(MCS0)， -70dBm(MCS7)， -89dBm(MCS8)， -68dBm(MCS15)
11ac： 20MHz：-88dBm(MCS0), -63dBm(MCS9) 40MHz：-85dBm(MCS0), -60dBm(MCS9) 80MHz：-85dBm(MCS0), -60dBm(MCS9)
Wi-Fi 6： 80MHz：-82dBm(MCS0), -57dBm(MCS9),-52dBm(MCS11) |
|
|
Maximum output power of the transmitter |
2.4GHz(2.4~2.4835GHz)：23dBm 5GHz(5.150~5.250GHz,5.725~5.850GHz)：23dBm (country-specific，comply with local laws) |
|
|
Adjustable Power |
1dBm |
|
|
Dimensions |
194mm×194mm×35mm (excluding mounting kits) |
|
|
Weight |
0.56kg (excluding mounting kits) |
|
|
Service Ports |
2 10/100/1000M Base-T Ethernet ports, PoE/LAN1 port supports PoE |
|
|
Management Port |
NA |
|
|
LED Indicator |
Single indicator (green light) |
|
|
Power Supply |
||
|
Power Consumption |
≤ 15.3W |
|
|
Environment |
Operating temperature: 0°C～40°C |
|
|
Storage temperature: -40°C～70°C |
||
|
Operating humidity: 5％～95％ (non-condensing) |
||
|
Storage humidity: 5％～95％ (non-condensing) |
||
|
Installation |
Ceiling/wall-mountable |
|
|
Safety Standard |
GB4943, IEC 62368-1 |
|
|
EMC Standard |
GB9254，EN301 489，EN50155，EN50121，EN55032，EN61000，EN55035 |
|
|
Vibration Standard |
IEC61373 |
|
|
Radio Standard |
EN300 328, EN301 893 |
|
|
MTBF |
>400000H |
|
|
Software Features |
||
|
Operating Mode |
AP mode and routing mode |
|
|
WLAN |
Maximum number of clients: 512 |
|
|
Recommended number of clients: 100 |
||
|
Up to 8 SSIDs |
||
|
Support SSID hiding Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID |
||
|
SSID-based and radio-based STA limit |
||
|
Support Layer 2 user isolation |
||
|
Roaming |
Support Layer 2 and Layer 3 roaming |
|
|
Security |
Support PSK authentication |
|
|
Support static blacklist and whitelist |
||
|
Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption |
||
|
Support Black List / White List： Maximum 256 rules per SSID Maximum 1024 rules per AP |
||
|
Routing |
Support static IP address, DHCP, PPPoE Dial Up |
|
|
Management and maintenance |
Support unified networking of all network equipment Support local or remote management with Ruijie Cloud app Support local management with web Support remote management with Ruijie Cloud platform |
|
|
Platform management features |
Automatic RF adjustment via the platform |
|
|
Unified configuration via the platform |
||
|
Unified monitoring via the platform |
||
